Automatic SRNE Solar Charge Controller 12V 24V 60 Amp For Home
Power System
SRNE patented solar charge controller PWM type 60A 12/24V auto with
LCD display for solar hoome system
Features of SR-HP2430/2440
1. Automatic identification system voltage
2. Charging program options for sealed, GEL and flooded lead-acid
batteries and lithium batteries are available.
3. The product provides overcharge, over-discharge, overload
protection, as well as short-circuit and reverse-connection
protection.
4. By virtue of an advanced load starting method, large-capacitance
loads can be started smoothly.
5. A range of parameter settings and power-down saving functions
are available ,thus requiring no repeated setting.
6. The product provides a dot matrix graphic LCD screen and a
human-machine interface with 2 keys.
7. The user-friendly design of browser and dynamic interfaces
ensures convenient and intuitive operations.
8. (An optional communication function) provides a RJ12 data port
(output of TTL232 level or bluetooth signals), with the data
adopting the standard Modbus protocol, can be used together with
our upper computer Monitoring software or mobile phone APP.
9. Boasting an industrial grade design, the product can function
well in various tough conditions.
10. TVS lighting protection is adopted.
we have rich experience in handiling orders for heavy buyers with
professional process.
- Stable raw material purchasing
- Favorable orders follow-up management
- Laudable lead-time & shipment control
- Traceable quality evaluation
- Flexible payment terms
- Remarkable after-sale service
Parameter
Parameter | Value |
Model | ML2420 | ML2430 | ML2440 |
System voltage | 12V/24V Auto |
No-load loss | 0.7 W to 1.2W |
Battery voltage | 9 to 35 |
Max. solar input voltage | 100V (25°C), 90V (-25°C) |
Max. power point voltage range | Battery voltage +2V to 75V |
Rated charging current | 20A | 30A | 40A |
Rated load current | 20A |
Max. capacitive load capacity | 10000uF |
Max. photovoltaic system input power | 260W/ 12V | 400W/ 12V | 550W/ 12V |
|
|
|
520W/ 24V | 800W/ 24V | 1100W/ 24V |
Conversion efficiency | ≤ 98% |
MPPT tracking efficiency | > 99% |
Temperature compensation factor | -3.0mv/ °C/ 2V (default) |
Operating temperature | -35°C to +45℃ |
Protection degree | IP32 |
Weight | 1.4kg | 2kg | 2kg |
Communication method | RS232 |
Altitude | ≤ 3000m |
Product dimensions | 210*151*59.5mm | 238*173*72.5 | 238*173*72.5 |
FAQ:
Q: what kind of certificates you have for your solar controllers ?
SRNE:Our solar controller has CE,ROHS,ISO9001 certificates
approved.
Q: Are you a manufacturer or trading company?
SRNE:We are a state-level high-tech enterprise that integrates
pluralism, R&D and manufacturing as one with PV controller,PV
inverter,PV energy storage oriented.And we have our own factory.
Q: Can I buy one sample for testing?
SRNE:Sure,we have a 8 years experience R&D team and in timely
after sale service,can help u fix any technicial problem or
confusion.
Q: How are about the delivery?
SRNE:
Sample:
1-2 working days
Order: within 7 working days depending on the order quantities
OEM Order: 4-8 working days after confirming the sample
Q: How're about your customers service?
SRNE:All solar controllers will be tested strictly one by one
before leaving factory,And the defective rate is
below 0.1%.we do try our best to provide a good customer service.
