    Intelligent PWM Solar Charge Controller 60A 12V 24V Auto IP30 Protection

    Intelligent PWM Solar Charge Controller 60A 12V 24V Auto IP30 Protection


    NEW PWM Solar Charge Controller SR-HP Series

    Main Feartures

    Except HP4840 /30, 12V/ 24 V system voltages are automatically recognized.
    Charging program options for sealed, GEL and flooded lead-acid batteries and lithium batteries are available.
    An upgraded 3-stage PWM charging algorithm is adopted. Application of an equalizing charge to the battery periodically or when over discharged, can effectively prevent the battery from non-equalization and sulfuration, thus extending the battery's service life (with the exception of GEL and lithium batteries).

    With temperature compensation employed, charging parameters can be automatically adjusted (with the exception of lithium batteries).
    A wide range of load working modes facilitate the product's application to different types of street lights and monitoring devices.

    The product provides overcharge, over-discharge, overload protection, as well as short-circuit and reverse-connection protection.
    By virtue of an advanced load starting method, large-capacitance loads can be started smoothly.
    A range of parameter settings and power-down saving functions are available ,thus requiring no repeated setting.
    The product provides a dot matrix graphic LCD screen and a human-machine interface with 2 keys.The user-friendly design of browser and dynamic interfaces ensures convenient and intuitive operations.
    (An optional communication function) provides a RJ12 data port (output of TTL232 level or bluetooth signals), with the data adopting the standard Modbus protocol, can be used together with our upper computer Monitoring
    software or mobile phone APP.
    Boasting an industrial grade design, the product can function well in various tough conditions.
    TVS lighting protection is adopted.


    FAQ
    Q1. What is your terms of packing?
    A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.

    Q2. What is your terms of payment?
    A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
    before you pay the balance.

    Q3. What is your terms of delivery?
    A: EXW, FOB, CFR, CIF, DDU.

    Q4. How about your delivery time?
    A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.

    Q5. Can you produce according to the samples?
    A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

    Q6. What is your sample policy?
    A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.

    Q7. Do you test all your goods before delivery?
    A: Yes, we have 100% test before delivery


    Intelligent PWM Solar Charge Controller 60A 12V 24V Auto IP30 Protection



    HP10A/20A

    HP30A/40A

    HP50A/60A

    Rated current

    10A/20A

    30A/40A

    50A/60A

    System voltage

    12V/24V Auto

    12V/24V Auto

    12V/24V Auto

    Max. Solar energy input
    voltage

    <55V

    Max. voltage at the battery end

    <34V

    Overvoltage protection

    16.0V

    Equalizing charging voltage

    14.8

    14.6

    -

    Boost charging voltage

    14.6

    14.4

    14.2

    Floating charging voltage

    13.8

    13.8

    13.8

    Charging recovery voltage

    13.2V

    Over-discharge recovery voltage

    12.5V(settable with the keys)

    Over-discharge voltage

    11.0V(settable with the keys)

    Light control voltage

    Light control on 5V, light control off 6 V (light control on plus 1 V)

    Light control
    judgment time

    10 minutes

    USB function

    yes

    yes

    yes

    IP protection degree

    IP30
