Intelligent MPPT Street Light Charge Controller 10A 12V 3 Year
Warranty
MPPT solar street light charge controller SR-DM120
Product Description
12v 24v Lithium Battery PWM MPPT Charger Solar light Solar charge
Controller
Features :
1). Advanced MPPT technology
2). High tracking efficiency up to 99.9%
3). Peak conversion efficiency of 98.4%
4). Ultra-fast tracking speed
5). Accurately recognizing and tracking MPP of multiple wave crest
6). Automatic PV power limit function
7). Multi-function LCD displays system information intuitively
8). User programmable for battery types, load control etc.
9). 3-Stage charge with MPPT charging
10). Common positive grounding design
11).Fully programmable function via remote meter, PC software and
Mobile APP.
12). Waterproof IP68 garde without any button.
Parameter of SR-DM120/DM160
| Parameter Name | Value |
| Model | DM120 | DM160 |
| Supported battery | Lead acid battery(gel included) and lithium battery |
| Battery voltage | 12V | 24V | 12V | 24V |
| Battery voltage range | 7V~32V |
| Charge current | 10A | 15A |
| Limited charge current |
| Solar panel power | 130W | 260W | 200W | 400W |
| Solar input voltage | 17V~60V | 34V~60V | 17V~60V | 34V~60V |
| Circuit efficiency | ≤95% | ≤97% | ≤95% | ≤97% |
| Voc of solar panel | <60V |
| MPPT tracking efficiency | >99% |
| Limited Charge voltage | 15.5V;×2/24V |
| Over voltage protection | 17.0V;×2/24V |
| Over-discharge voltage | 7.5V~15.5V;×2/24V |
| Max load power | 60W | 120W | 80W | 160W |
| Output voltage range | 15V~60V | 30V~60V | 15V~60V | 30V~60V |
| Output current range | 70~4200 mA | 70~5600 mA |
| Output current accuracy | ±3% or ±30mA |
| Light control voltage | 5V~15V;×2/24V |
| Working temperature | -40℃ ~ +60℃ |
| Weight | 390g | 490g |
| Product dimension | 114×88.3×24.5(mm) | 142×88.3×24.5(mm) |
| Protection | 1. IP68 degree; 2. PV and Battery reverse connection; 3. internal overheat; 4. PV over voltage, short circuit; 5. charge,discharge over load; 6. Anti converse charge at night; 7.TVS protection to PV. 8. Load short circuit, open circuit ; 9. Battery open circuit |
Why choose us?
SRNE, as a high-tech enterprise with the government support ,and
with own R&D team as well as factory, has become the famous
brand and the experts of PV storage management and control, we
always insist on good quality, professional service and leading
technology. Besides, customer can purchase premium products with
favorable prices from us.
Our R&D team and service: in SRNE, there' re some technicians
having more than 10 years experience in the field of solar
controller and all the products we design are the trend of market
development.
Our tenet is continuously in pursuit of warm customer service.
FAQ:
Q: what kind of certificates you have for your solar controllers ?
SRNE:Our solar controller has CE,ROHS,ISO9001 certificates
approved.
Q: Are you a manufacturer or trading company?
SRNE:We are a state-level high-tech enterprise that integrates
pluralism, R&D and manufacturing as one with PV controller,PV
inverter,PV energy storage oriented.And we have our own factory.
Q: Can I buy one sample for testing?
SRNE:Sure,we have a 8 years experience R&D team and in timely
after sale service,can help u fix any technicial problem or
confusion.
Q: How are about the delivery?
SRNE:
Sample:
1-2 working days
Order: within 7 working days depending on the order quantities
OEM Order: 4-8 working days after confirming the sample
Q: How're about your customers service?
SRNE:All solar controllers will be tested strictly one by one
before leaving factory,And the defective rate is
below 0.1%.we do try our best to provide a good customer service.
