Lighting Intelligent Pwm Solar Charge Controller 15A IP68 AC DC
Charge
SRNE solar charge controller hybrid type AC/DC plus solar SR-EH120
12/24V 15A
Features of SR-EH120
1. With an all-new wireless remote control design, a hand-held
device can be used to modify controller parameters and read system
information.
2. Fully-digital and high-precision constant current control
boasting an efficiency of up to 96%.
3. Supports 12 V and 24 V lead-acid batteries and lithium
batteries.
4. Features a DC detection function. If DC available, the system
will automatically switch to DC power supply when the battery
voltage falls to the DC switching point; if DC powers off, the
system will shut off output when the battery reaches the
over-discharge point after continuous discharging.
5. Boasts an adjustable operating current range of 0.15 A from 3.96
A and an adjustment precision of 30 mA.
6. Employs a load triple-stage dimming and morning light design,
with an operating duration adjustable from 0 to 15 hours and a
power settable from 0 to 100%.
7. Data communication adopts a multi-time two-way handshake
protocol and a data compression algorithm, realizing precise and
fast data transmission.
8. True constant current rather than current-limiting control
ensures smooth and stable output current, effectively reducing LED
light attenuation and extending LED service life.
9. A metal case and an IP68 waterproof level enable the device to
operate in various kinds of tough conditions.
10 Adopts an improved charging algorithm to reduce the
vulcanization effect caused by battery over-discharging,
significantly extending the battery's service life.
Main Advantages
LCD display , easy to operate on LCD screen
Multi stage charging (3-stage charging , parallel charging and
equalized charging function)
BTS – Battery remote temperature sensor terminal
Enable to charge Li-thium, Gel , lead-acid battery
With RS485 & USB communication port
Protection: PV array short circuit, PV reverse polarity, Battery
reverse polarity, Over charging, Output short circuit
Parameter of SR-EH120
Parameter | EH120 |
Supported battery type | Lead-acid batteries (including gel batteries), lithium batteries |
System voltage | 12V/ 24V |
Output power | 12V/ 60W 24V/ 120W |
Output current | 0.15 to 3.96A |
No-load loss | 9mA/ 12 V; 12mA/ 24 V |
Charging current | 15A |
Solar panel input voltage | < 55 V |
Typical constant current source efficiency | 90% to 96% |
Over-voltage protection | 16.0V; × 2/24 V |
Charging voltage limit | 15.5V; × 2/24 V |
Current accuracy | ±3% |
Load output voltage | < 60V |
Over-temperature protection | Ambient temperature: 80℃ (load downrating power) |
Operating temperature | -35 to 65℃ |
Protection degree | IP68 |
Weight | 280g |
Dimensions (mm) | 120*82*20 |
Why choose us?
SRNE, as a high-tech enterprise with the government support ,and
with own R&D team as well as factory, has become the famous
brand and the experts of PV storage management and control, we
always insist on good quality, professional service and leading
technology. Besides, customer can purchase premium products with
favorable prices from us.
Our R&D team and service: in SRNE, there' re some technicians
having more than 10 years experience in the field of solar
controller and all the products we design are the trend of market
development.
Our tenet is continuously in pursuit of warm customer service.
FAQ:
Q: what kind of certificates you have for your solar controllers ?
SRNE:Our solar controller has CE,ROHS,ISO9001 certificates
approved.
Q: Are you a manufacturer or trading company?
SRNE:We are a state-level high-tech enterprise that integrates
pluralism, R&D and manufacturing as one with PV controller,PV
inverter,PV energy storage oriented.And we have our own factory.
Q: Can I buy one sample for testing?
SRNE:Sure,we have a 8 years experience R&D team and in timely
after sale service,can help u fix any technicial problem or
confusion.
Q: How are about the delivery?
SRNE:
Sample:
1-2 working days
Order: within 7 working days depending on the order quantities
OEM Order: 4-8 working days after confirming the sample
Q: How're about your customers service?
SRNE:All solar controllers will be tested strictly one by one
before leaving factory,And the defective rate is
below 0.1%.we do try our best to provide a good customer service.
